Synopsis

X660 G45 is a high-performance computing platform specially developed for deep learning training. It uses the latest Intel® Xeon® scalable processor to provide powerful platform support for GPU computing, and is equipped with 8 NVIDIA® Tesla® SXM4 A100 GPUs.

Product Highlights

Product Features

High-performance computing architecture

Fully equipped with 8 NVIDIA® Tesla® SXM4 A100 GPUs, with 4 PCI-E switch architectures to provide NVIDIA® NVLINK™ interconnection, and connect to GPU through PCI-E switch. It supports up to 8 GPUs with their own special-purpose 200G network and U.2 storage. Make information interaction faster and easier to use.

Designed for huge computing clusters

Supports up to 8x A100 Nvlink GPUs + 8x 200G rapid network communication. Cooperate with 200G network switching equipment to implement network deployment and build GPU high-speed clusters. Complete massive concurrent online data processing while distributing the results to user terminals.

Independent design, support full-function customization

All main components of the server, BIOS, and BMC software are all independently designed to provide users with on-demand customization functions to meet special specifications and management requirements of users' computer rooms during batch deployment

Technical Specifications

Form

6U rack-mounted server chassis

Processor

Supports 2 third-generation intelligent Intel® Xeon® scalable processors

Chipset

IntelC621A series chipset

RAM

32 DDR4 memory slots 3200MHz, support for memory ECC

Local storage

Supports 12x 3.5/2.5-inch hard disks; (8 U.2 SSDs) 8x 2.5-inch switch directly connected to U.2 hard disk 2x M.2 (PCIe/SATA adaptive)

Network

Optional 10 Gigabit dual-port RJ45, 25G dual-port fiber, 10 Gigabit dual-port fiber and other network interfaces

PCI-E expansion

Supports up to 10 PCI-E4.0 slots (support 1 OCP)

GPU expansion

8 NVIDIA® Tesla® SXM4 A100 (40G/80G)

Other ports

2 independent IPMI management interfaces 2 front USB3.0 interfaces 2 rear USB3.0 interfaces 2 rear USB2.0 interfaces (serial port) 1 front VGA interface 1 rear VGA interface

Power supply

Optional 54V 3000W or 3500W CRPS high-efficiency platinum power supply, optional 3+1 or 2+2 redundant voltage range 100-240Vac (please refer to the power input value on the nameplate label of the host)

Management function

Integrated with dual BMC chips, it supports advanced management functions such as IPMI2.0, SOL, KVMOverIP and virtual media, provides 1 1Gbps RJ45 management interface externally, and supports NCSI function

Graphics card

Integrated display controller, resolution 1920×1080

Operating System

For the details of Microsoft®WindowsServe, RedHatEnterpriseLinux, SUSELinuxEnterpriseServer, Ubuntu, etc., please contact Nettrix Hotline 400-898-1688

Operating temperature

5 ℃ ~35 ℃ when working (please consult Nettrix Company for details)

Chassis specification

263.5mm(H)x481mm(W)x798mm(D)

Full configuration weight

85KG
