Synopsis

Nettrix X640 G40 is an all-round GPU server with both training and reasoning functions. It adopts the latest generation of dual-channel Intel® Xeon® scalable processor, supports up to 8 training GPUs, and provides comprehensive performance support for high-density GPU computing. The product supports a variety of different GPU topologies, and optimizes GPU interconnection for different applications and models. It is an efficient and all-round computing platform. At the same time, it has been adapted to the mainstream GPUs on the market, and is perfectly compatible with a variety of GPU types. Meets the flexible needs of customers.

Product Highlights

Product Features

Supports high-intensity GPU computing

Supports the third-generation intelligent Intel® Xeon® scalable processor, provides a powerful X86 processing platform for training applications, supports 8 NVIDIA®Tesla®A100/ NVIDIA® Tesla® A40 full-speed 7*24h work, supports 8 NVIDIA® Tesla® A10/T4 and provides online big data processing

Flexible configuration, optimized performance

8 GPUs for high-performance online reasoning: 8 professional cards are interconnected to optimize the efficiency of GPU Direct for deep learning training. High-density bit stream processing: simultaneous access to 8 NVIDIA® Tesla® T4 to achieve more than 100 channels of high-definition processing cost-effective HPC

Rich expansion, optimized management

Supports high-speed network, storage and other IO expansion, 16 U.2 hard disks. Provides high-end computing platforms with high-speed transmission and data storage capabilities, At the same time, it further optimizes the efficiency of operation and maintenance, and has a professional management platform that can realize the recognition, monitoring, fan speed control support, fault alarm and other functions of different mainstream GPUs in the market.

Technical Specifications

Form

4U rack-mounted server chassis

Processor

Supports 2 third-generation intelligent Intel® Xeon® scalable processors

Chipset

IntelC621 A series chipset

RAM

32 DDR4 memory slots 3200MHz, support for memory ECC

Local storage

Supports 24 3.5-inch hard disks; supports 16 U.2 SSDs and 2 M.2 SATA SSDs

Network

Optional 10 Gigabit dual-port RJ45, 25G dual-port fiber, 10 Gigabit dual-port fiber and other network interfaces

PCI-E expansion

Supports up to 12 PCI-E4.0×16 slots (support 1 OCP network card )

GPU expansion

Including but not limited to: NVIDIA® Tesla® A100 NVIDIA® Tesla® A40 NVIDIA® Tesla® A10 NVIDIA® Tesla® T4 NVIDIA® Tesla® RTX 8000/6000/5000/4000 For other GPUs, please consult Nettrix Hotline 400-898-1688

Other ports

1 independent IPMI management interfaces 2 front USB3.0 interfaces 2 rear USB3.0 interfaces 1 front VGA interface 1 rear VGA interface

Power supply

Optional 1200W/1600W/2000WCRPS high-efficiency platinum power supply, optional 3+1 or 2+2 redundant voltage range 100-240Vac (please refer to the power input value on the nameplate label of the host)

Management function

Integrated with dual BMC chips, it supports advanced management functions such as IPMI2.0, SOL, KVMOverIP and virtual media, provides 1 1Gbps RJ45 management interface externally, and supports NCSI function

Graphics card

Integrated display controller, resolution 1920×1080

Operating System

For the details of Microsoft®WindowsServe, RedHatEnterpriseLinux, SUSELinuxEnterpriseServer, Ubuntu, etc., please contact Nettrix Hotline 400-898-1688

Operating temperature

5 ℃ ~35 ℃ when working (please consult Nettrix Company for details)

Product certification

Through CCC and other certifications

Chassis specification

175.8mm (height) x432mm (width) x798mm (depth)

Full configuration weight

84KG
