Nettrix R610 G30 is a high-density rack server. Equipped with Intel® Xeon® scalable processors, the server enables sound integration of performance, density and expandability with more intensive deployment and effective space utilization of data centers. The server applies to industries demanding on density of deployment, e.g., Internet, communication or cloud computing.

Product Highlights

1. Intensive deployment 2. Lower data center O&M cost

Product Features

Brand-new platform with amazing performance

● Available for 2nd Gen Intel® Xeon® scalable processors ● Amazing computing performance under brand-new 3 UPI interconnection architecture, with bus bandwidth up to 10.4 GT/s ● Available for DDR4 2933MHz memory frequency, with an increased memory bandwidth of 20% compared to the previous generation product

Intensive and flexible expandability

● 1U space architecture enables more computing kernels in the same space ● Four 3.5-inch or eight 2.5-inch hard drives and compatibility with NVMe SSD to fully enable personalized memory resources Integrated gigabit NIC, flexibly expandable to OCP NIC and PCI-E plug-in NIC to enable personalized network recourses

Intelligent power consumption management

● For large data centers, coupled with open management platform to fully cover multiple management protocols such as RedFish, IPMI and SNMP ● Optimized O&M efficiency with features of health monitoring and report of key units to enable intelligent operation and maintenance service in product life cycle ● Coupled with new high-efficiency energy-saving intelligent speed control design to enable the whole server to dissipate heat according to the ambient temperature and load, improvethe power consumption without affecting the load performance, and achieve the business appeal of energy conservation

Technical Specifications


1U rack server


Available for two 2nd Gen Intel® Xeon® scalable processors


Intel C620 Series Chipset


Twenty-four DDR4 memory slots, 2933 MHz; available for memory ECC, memory mirroring, memory sparing and other protected modes; compatible with twelve DCPMM memories, 2666 MHz

Storage controller

Available for directed mode, RAID0, RAID1, RAID10, RAID5, RAID50, RAID6, RAID60 and other storage modes When the RAID controller is used, super capacitor of Cache protection and features as RAID level migration, disk roaming, self-diagnosis and Web remote setup are available

Local storage

Front: available for four 3.5-inch or eight 2.5-inch hard drives and compatible with four NVMe hard drives Built-in: one SATA/PCI-EM.2 + one PCI-EM.2, two SD cards

Network interface

On-board NIC: 2 GE interfaces and 1 OCP, with NCSI function OCP can be configured with many interfaces, such as 2*GE, 2*10GE and 2*25GE


Available for expansion to five PCI-E 3.0 expansion slots, including one special slot for hard drive controller and one OCP slot

Other interfaces

One RJ-45 management interface at the rear of the cabinet Four USB 3.0 interfaces, including two at the rear of the cabinet and two at the front of the cabinet One VGA interface at the rear of the cabinet, front VGA optional One optional serial port at the rear of the cabinet Two SD card slots inside the cabinet

Power supply

550W/1200W high-efficiency platinum hot-plug power supply, available for 1+1 power supply redundancy, voltage range: 100-240 V AC (Please refer to the power input value on the nameplate label of the computer host)

Fan module

8 hot-plug fan modules, available for N+1 fan redundancy


Integrated BMC chip with external one 1Gbps RJ45 management interface, available for Redfish, SNMP, IPMI 2.0 and other standard interfaces; remote management inter face based on IKVM/HTML 5, with functions of comprehensive fault diagnosis, auto mated O&M, and remote management

Graphic card

Integrated display control unit, resolution: 1920x1080

Operating system

Microsoft® Windows Server, Red Hat Enterprise Linux, SUS ELinux Enterprise Server, CentOS, Ubuntu Vmware EXSI and others. Please call Nettrix hotline 400-898-1688 for more information

Working temperature

5℃-45℃ when working (please contact Nettrix for more information)

Product certification

CCC and others

Cabinet size

43.5mm (height)x432mm (width)x803.5mm (depth) 43.5mm (height)x482 (including lugs) mm(width)x814 (including hand screws) mm (depth)

Weight under full configuration

27kg (excluding guide rail)
